Holmium lasers are solid-state lasers with a high absorption coefficient in water, making them easily absorbed by human tissue and producing cutting and ablation effects.
Holmium laser is a new type of laser produced by a pulsed solid laser device made of laser crystals (Cr:Tm:Ho:YAG) with yttrium aluminium garnet (YAG) as the activating medium and doped with sensitised ion chromium (Cr), energy transfer ion thulium (Tm) and activated ion holmium (Ho).
| Mode | DHL-1-A | DHL-1-B | DHL-1-C | DHL-1-D | DHL-1-E | DHL-1-F | DHL-1-G |
| Output Power | 20W | 30W | 45W | 60W | 75W | 90W | 100W |
| Wavelengths | 2.1μm(2100nm) | ||||||
| Energy per PulseRe | 0.1~5.0J， adjustable | ||||||
| petition Rate | 1~50Hz，adjustable | ||||||
| Pulse Duration | 300μs~600μs,adjustable | ||||||
| Delivery system | Multi-specification Optical Fiber and Flexible Endoscopic.200μm、365μm、550 μm、1000 μm | ||||||
| Aiming Beam | 632nm/532nm(optional),output power <5mw | ||||||
| Cooling Mode | Suitable for Sealed circulating water cooling, compressor refrigeration | ||||||
| Electrical | 220V、60Hz | ||||||
1.High Power,Large Energy,
Functional Diversity
2.Multi Pumping Cavities Laser Coupling
Output Technology (Multi-Core)
3.Laser Coupling Protection System
4.Intelligent Optical Fiber System
5.Having Power On Self Test System
Delivery within 3-15 days after receipt of payment, delivery may be a little later for large or customized products, but not much later.
Yes, the sample freight needs to be paid by the customer.
Most of our products are available for OEM & ODM with your logo and design. For more details, leave us a message via Whatsapp, or Mail.
