Rich configuration, advanced technology, complete functions, widerange of applications, the first enterprise with registration certificateof 5.5/6.4KW.
All-electric movement. automatic bulb tube tracking and positioning LCD screen for convenient operation and intelligent application experience.
One、working conditions
1、Environmental requirements：
Ambient temperature：10℃～40℃
Relative humidity：30％～75％
Atmospheric pressure：70～106kPa
2、Power requirements：
Power supply voltage：220Ｖ，50Hz
Internal resistance of the power source：≤1.0Ω
Power supply capacity：≥3.5kVA
Two、Applicable scope
Suitable for emergency departments, general surgery, spinal surgery, orthopedics, urology, gynecology, trauma care, pain management, radiology, plastic and aesthetic surgery, operating rooms, etc., for X-ray examination and diagnosis. It can be used for retrieving foreign objects from the body, lumbar surgery, bone setting, reduction, and nailing.
Three、Oil-cooled modular high adaptability X-ray tube
1、Focus size： small focus 0.6mm major focus 1.0mm
2、Anode heat capacity：200KHU
3、Heat capacity of the tube fitting：800KHU
Four、High-voltage generator
1、Output power：3 .5KW
2、Working frequency：100KHz （Ultra-high frequency design, with frequencies reaching the highest in the country, ensures high-definition image quality while radiation is significantly lower than national standards）
3、X-ray current：0.3mA～4mA（stride 0.1mA）
4、X-ray current：30mA～50mA
5、Perspective、X-ray voltage：40KV～110KV（stride 1KV/10KV）
6、Exposure time product of radiography current：1mAs～100mAs
1.Rich configuration, advanced technology, complete functions, widerange of applications, the first enterprise with registration certificateof 5.5/6.4KW.
2.Leading 100KHZ high frequency high voltage generatorwith ultralow radiation and ultrahigh definition.
3.Oil-cooling combined high sealing high temperature resistant tubewith stable performance and strong heat-resistance, could satisfy therequirement of long time operation.
4.All digital design, the core parts adopt imported components, highcompatibility, create perfect images chain, more exquisite pictures
5.Modular design with functions of automatic error examination andcorrection, easy to maintain.
6.lBS intelligent brightness control system could offer the optimal dosevalue according to the tissue density of imaging body part.
7.Unique dual-screen different display technology, comparison ofdynamic and static images, easy for real-time lesion observation.
8.Convenient and flexible movement, pluggable connecting wire ofmain engine and work station, lower failure rate, efficient manualmode of mechanical movement.
